TEST ENGINEERING
Test Engineering Services
We believed that A well planned test strategy can ensure a well designed product can be successfully released and achieve the fullest potential in the market. HTP can apply experiences from a wide range of product test solutions to put the correct test strategy in place. Product technology, component selection, product criticality, and product complexity have been considered when investigating a test strategy. By reviewing relevant characteristics of a product, key test requirements are derived. Then the most appropriate test method can be implemented to achieve a real goal: -- complete test coverage.
HTP OFFERS
- Co-work with customer for Design for Test in development stagev
- Implemented test procedure developed by customer
- In-Circuit Testing (ICT) and equipment development
- Functional Testing (FCT) at the board and systems levels Systems-level.
- Dynamic burn-in capabilities
- Full temperature cycling
- Trouble shooting to the component level
- Testing procedures and reports
- Yield analysis for future defect prevention
In-Circuit Testing Test
TR-518FE
- Auto-Learning and Automatic Program Generation of Open/Short, Pin Information, IC Clamping Diode,Test Jet Technology
- Allocate defect device and pin instantly
- High capacity rack design, test points up to 3584
- With IC Clamping Diode test technologies, can enhance the testing coverage of BGA package
A) Display Color Analyzer CA-210
- High-speed gamma measurement
- Support for flicker measurement (using the LCD Flicker Measuring Probe)
- Capable of measuring luminance as low as 0.1 cd/m2, the CA-210 can be used for gamma correction and measurement.
- Color measurements can be obtained with an accuracy of ±0.002 for white and ±0.004 for primary colors.
- Uses XYZ filters to approximate CIE 1931 Standard Observer.
B) Quantum Data 802BT Video Test Generator
- Pixel repetition test suite
- 32, 44.1, 48, 88.2, 176.4 and 192KHz audio sampling rates
- Generate all EIA/CEA-861-B formats up to 165MHz, with all possible variations
- HDCP 1.1 support for testing repeaters
C) Audio Precision SS-2722 Audio Analyzer
- Dual domain
- Two-channel analog input/output, analog Analyzer and Generator
- DSP analyzer and generator, plus 192k digital input/output
- Fast instrument operation and powerful analysis under sophisticated control software.
- Programmatic control for high-speed automation.
- Serial digital interface testing.
A) Drop test
- Package maximum mass: 100Kg
- Package Maximum drop height: 1800mm
- Package dimensions: 840x780x1000 (mm)
- Drop mode: face, edge, angle
- Maximum mass of packing 136KG
- Revised package dimensions 1400x800x800
B) Vibration test
- Maximum experimental load: 100Kg
- Load displacement amplitude: 25mm
- Maximum acceleration amplitude: 3000mm
- Vibration direction: circuitous
- Fixes and maximum experimental load: 136Kg
- Level of vertical vibration and horizontal vibration +
C) Environmental stress screening
- Programmable temperature machine TE0841
0 deg C to 60 deg C
40 deg C to 95 deg C
